Features

Economy and Energy Saving
Utilizes intelligent power control to dynamically distribute energy in real time, ensuring fast compound action response and reducing fuel consumption by 10%–15%.

Intelligent Upgrade
Features a high-resolution touchscreen with a 3ms refresh rate for seamless display. SANY’s proprietary locking visualization system enhances operational visibility, helping prevent wear and Kelly bar accidents.

Easy Maintenance
External rotary drive key allows for quick access and maintenance. The wedge-type main winch rope connection simplifies installation and removal. Lubrication is made easier via a dedicated point connected to a grease outlet hose.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 300/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5~25rpm

Rated Output Torque: 360kN·m

Pile

Max. Pile Diameter: 2500mm

Max. Pile Depth: 100/65m

Crowd System

Crowd Force: 290kN

Stroke: 6000mm

Line Pull: 335kN

Overall Machine

Overall Height: 26365mm

Operating Weight: 120T

Transport Width: 3530mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 360kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3329000

Request for quote: +971525384269
