The SANY SKT90E Electric Off-Highway Mining Truck is engineered for heavy-duty mining tasks with an eco-friendly edge. Its advanced electric drive system enhances efficiency while reducing operating expenses. Built with a strong frame and reliable components, it ensures safe and steady performance in demanding terrains. Producing zero exhaust emissions, it contributes to cleaner mining practices. This model reflects SANY's dedication to innovation and sustainable productivity.

Features-

High-strength Frame: The newly designed low-stress and high-strength frame effectively prevents fatigue breakage of the frame and reduces the overall stress level by 51% compared with competing products.

Hydro-Pneumatic Suspension: The hydro-pneumatic suspension technology is applied to replace the traditional leaf spring structure, remarkably improve the life and comfort of the machine, thoroughly solve the frequent breakage problem of front suspension leaf springs in the industry, and promote the attendance rate of the machine. The hydro-pneumatic suspension features excellent shock-absorbing and damping performance to remarkably improve the load application of the frame and prolong the life of the frame.

Oil and Gas Suspension: Front oil and gas suspension, buffer, and vibration reduction are significantly improved; Maximizing the impact force of the frame, cab, and other heavy parts, reducing the occurrence of various faults, and extending the life of the vehicle; Thoroughly solve the fracture problem of the front plate spring.

Full Hydraulic Steering and Emergency Steering: The vehicle steering makes it easier to solve the problem of heavy mechanical steering caused by heavy trucks in the industry; Equipped with emergency steering, to solve the problem of steering failure after engine flameout or steering pump failure.

Intelligent Electrical System: (i). SANY intelligent control module with an electrical fault self-diagnosis system can troubleshoot some problems automatically.

(ii). 10 "central control screen equipped with reversing camera, Bluetooth connection, compatible with intelligent mine management system. The built-in GPS module can effectively monitor the vehicle operation.

Parameters-

Net Weight: 37T

Gearbox Type: Dual 3-shift AMT

Capacity (Struck/Heaped): 33/38m³

Size: 9145x3660x4395mm

Left/Right Hand Drive: Left/Right

Total Power: 740kW

Displacement: 0L

Maximum Torque: 2300NM

Max. Gradeability: 39%

Min. Turning Radius: 12500mm

Lubrication System: Optional automatic lubrication

Automatic/Manual: Automatic

Axle: 25+35+35(t)

Tire: 16.00R25

Load Weight: 60T
